MTP400 Microplate Incubator (PID fuzzy control)
PID fuzzy control automatically adjusts the heating rate, shortens waiting time, and ensures precise and stable temperature for sample incubation on microplates and deep-well plates.
Overview
Features
- Clear display: real-time setup and operating status; easy to use.
- Supports standard microplates and deep-well plates; capacity up to 4 plates.
- Automatic preheating for a fast start.
- Auto-resume: resumes operation after power failure.
- Temperature calibration function for laboratory accuracy.
- Built-in software and hardware over-temperature protection for safety.
Useful in practice
- To reach set temperature faster, activate Auto preheating 15–20 min before use.
- For accuracy ≤±0.5 °C, operate in a stable room temperature environment without airflow.
- When using deep-well plates, ensure full contact between plate and heating surface for best uniformity.
Technical specifications
| Parameter | Value |
|---|---|
| Temperature setting range | 0–80 °C |
| Temperature control range | RT+5–80 °C |
| Temperature accuracy | ≤±0.5 °C* |
| Temperature uniformity | ≤±0.5 °C* |
| Display accuracy | 0.1 °C |
| Heating time | ≤10 min (from RT to 80 °C) |
| Timer | 1 min – 99 h 59 min / ∞ |
| Auto preheating | Yes |
| Auto resume (after power failure) | Yes |
| Capacity | 4 standard microplates or deep-well plates |
| Power supply / Power | 300 W |
| Voltage / Frequency | AC 220 V or 110 V, 50–60 Hz |
| Fuse | 250 V 3 A Φ5×20 |
| Dimensions (W×D×H) | 340 × 320 × 200 mm |
| Weight | 6.5 kg |
*Typical values under stable ambient conditions and proper load.
Downloads
- 📘 Catalog (PDF)
- 🧾 User Manual
