DRYSD230 Laboratory Drying Oven Standard 230L


DRYSD laboratory drying oven with Digital microprocessor display.

 Digital temperature control
 High temperature uniformity
 Heating temperature range RT+10 to 300°C
 Corrosion resistant steel chamber with rounded corners
 Built in glass for sample observation
 Auto control fan speed
 Function self check in
 Shelves 2 supplied
 Timer function 0 – 9999 min

1.835,00

Download Catalog

High temperature uniformity

High capacity

Max temperature up to 300C

SKU: PRO3014 Category: Tag:
Drying Oven Air Circulation

Display Type

LCD

Drying Oven Capacity

Drying Oven Dual Temperature Limiter

No

ItemDRYSD30DRYSD45DRYSD65DRYSD85DRYSD125DRYSD230DRYSD625
Volume Litter30456585125230625
 Air CirculationForced  Air Circulation (Convection)
Temperature rangeRt+5 – 300°C
Temperature resolution0,1°C
Temperature fluctuation1°C
Display typeLED
Temperature control modeTwo temperature section PID intelligent, sensor deviation correction, self tuning,
Adjustable exhaust air flapØ28mm on top with function of test hole
Timer0-9999min with timing wait function
HousingCold rolling still with electro static spraying exterior / DRYSE – embossed SUS304
Temperature sensorPt100
Door with tempered glass observation windowSeries DRYSD has equipped with tempered glass, Series DRYSE without tempered glass
Operation functionTemperature settings, timing function, auto stop, internal parameter locking, temperature correction, auto tuning, parameter memory in the case of electrical cut off, over temperature sound and light alarm
Standard shelf number2
Optional shelf number (max)679913177
Load per shelf (max)15kg
Voltage220V/50-60Hz220/380V
Power0,8kW1,2kW1,6kW2kW2,5kW3kW5kW
Inner chamber size W*L*H mm310*310*310350*350*350400-360*450450*420*450500*450*550600*500-750660*760*1250
NV/GV kg33/3737/4344/4960/5680/9094/120120/160
Standard Temperature Certificate At 160°C in the chamber centre Issued by COLO technical service
Temperature certificate (optional)One or multi point temp, mapping, issued by accredited laboratory
Optional accessoriesShelf, RS485 interface, Printer, Program Temperature Control device, Remote control, WF control, Temperature Controller with ramp settings, USB data storage, Touch Screen Display,
