AFPT900 Abel Flash Point Tester ISO 13736 Closed Cup method
Overview
The AFPT900 Abel closed-cup flash point tester is designed for determining the flash point of petroleum products and other liquids per IP 170, ISO 13736 and GB/T 21789. It covers low flash points down to −30 °C with a circulating cold source and is optimized for samples with flash points between −5 °C and 66.5 °C.
Key features
- Solid-state voltage regulator with digital heating voltage display for precise heating rate control.
- Adjustable motor stirrer (0–40 rpm); stirring auto-stops during ignition.
- One-button ignition performs slide cover action and ignition automatically.
- Top-mounted stirring device on cup cover; easy to remove for cleaning.
- Independent fine adjustment for pilot and test flames on gas line.
Technical specifications — AFPT900
| Standards | IP 170; ISO 13736; GB/T 21789 |
|---|---|
| Measuring range | −30…70 °C (with circulating cold source) |
| Applicable precision range | Flash points −5…66.5 °C |
| Heating power / rate | 0–450 W, continuously adjustable; ~1 °C/min |
| Stirring speed | 0–40 rpm, continuously adjustable |
| Flame size | 3–4 mm diameter (adjustable) |
| Environment | 5…35 °C; RH ≤85%; clean, non-corrosive, low EMF/airflow |
| Power / gas | AC 220 V ±10%, 50 Hz; LPG/propane fuel |
| Dimensions / weight | 390 × 270 × 430 mm; 12 kg |
